Ceph Cluster OSD Removal Guide

Overview

This document explains step-by-step how to safely remove OSDs from a live Ceph cluster without data loss or downtime. Continuously monitoring the cluster's health during the process is critically important.

Preparations

Step-by-Step Process

1. Mark the OSD as "Out"

Command:

ceph osd out <osd_id>

Example:

ceph osd out 34

Note: When the command is executed, you should receive the message "marked out osd.34."

"

2. Monitor Cluster Status

Purpose: Ensure the rebalance process is complete.

Command:

ceph -s

Checkpoints:

3. Removing the OSD from the CRUSH Map

Purpose: Remove the OSD from the CRUSH map so it no longer participates in the cluster's data distribution.

Command:

ceph osd crush remove <osd_name>

Example:

ceph osd crush remove osd.34

Checkpoints:

4. Removing OSD Authorization

Purpose: Remove the authentication information associated with the OSD.

Command:

ceph auth del osd.<osd_id>

Example:

ceph auth del osd.34

5. Removing the OSD from the Cluster

Purpose: Completely delete the OSD's record from the Ceph cluster.

Command:

ceph osd down <osd_id>

ceph osd rm <osd_id>

Example:

ceph osd down 34

ceph osd rm 34

Sometimes the ceph osd down command works, but the rm command might not. In that case, you may need to stop the service on the OSD node using systemctl.

systemctl stop ceph.34.service

Example: Removing an OSD Node

ceph osd crush rm <node name>

We are removing the node from the crush map.

ceph orch host drain <node name>

We are removing all services from the node by draining it.

ceph orch daemon rm osd.34 --force

We are removing the remaining OSDs on the node as a daemon.

ceph orch host rm <node name>

Finally, we completely remove the node. It will no longer appear in our host list.

Additional Notes

Process Intervals:

After each step, be sure to check the cluster status with the ceph -s command. Only proceed to the next step once it is in a healthy (active+clean) state.

Total Number of OSDs:

If there are 35 OSDs in the cluster and you want to remove, for example, 15 OSDs, perform the operation in small groups (2-3 at a time) instead of removing them all at once.

Conclusion

By carefully following these steps, you can remove OSDs from a live Ceph cluster without any downtime. Continuously monitoring the cluster's health and proceeding in small steps will help prevent data loss and performance issues.
